1, chemische Zusammensetzung
Klasse | N | C | H | Fe | O | Al | V | Pa | Mo. | Ni. | Ti. |
GR1. | 0.03 | 0.08 | 0.015 | 0.2 | 0.18 | / | / | / | / | / | bal. |
GR2. | 0.03 | 0.08 | 0.015 | 0.3 | 0.25 | / | / | / | / | / | bal. |
GR3. | 0.05 | 0.08 | 0.015 | 0.3 | 0.35 | / | / | / | / | / | bal. |
GR4. | 0.05 | 0.08 | 0.015 | 0.5 | 0.4 | / | / | / | / | / | bal. |
GR5. | 0.05 | 0.08 | 0.015 | 0.4 | 0.2 | 5,5 ~ 6.75. | 3,5 ~ 4.5. | / | / | / | bal. |
GR7. | 0.03 | 0.08 | 0.015 | 0.3 | 0.25 | / | / | 0,12 ~ 0,25. | / | / | bal. |
GR9. | 0.03 | 0.08 | 0.015 | 0.25 | 0.15 | 2,5 ~ 3.5. | 2,0 ~ 3.0. | / | / | / | bal. |
GR12. | 0.03 | 0.08 | 0.015 | 0.3 | 0.25 | / | / | / | 0,2 ~ 0,4. | 0,6 ~ 0.9. | bal. |
2, Zuganforderungen
| Klasse | Spannstärke (≥) | YEILD -Stärke (≥)) | Dehnung (≥)%) | ||
| ksi | MPA | ksi | MPA | ||
| Gr1 | 35 | 240 | 20 | 138 | 24 |
| Gr2 | 50 | 345 | 40 | 275 | 20 |
| GR3 | 65 | 450 | 55 | 380 | 18 |
| GR4 | 80 | 550 | 70 | 483 | 15 |
| GR5 | 130 | 895 | 120 | 828 | 10 |
| Gr7 | 50 | 345 | 40 | 275 | 20 |
| Gr9 | 90 | 620 | 70 | 483 | 15 |
| GR12 | 70 | 483 | 20 | 345 | 18 |
| GR23 | 120 | 828 | 110 | 760 | 10 |
| Produktname | Klasse | Spezifikationen (mm) | ||||
| Außendurchmesser | Innendurchmesser | Abschnitt Höhe. | Ringmaterialdicke. | Standard | ||
| Titan-Disc. | Gr1 gr2 GR5 GR7 GR9 GR12 | 150--300. | / | 35-140. | / | ASTM B381. |
| > 300--500. | / | 35-150. | / | |||
| > 500--600. | / | 40-110. | / | |||
| Titanring | 200-400. | 100-300. | 35-120. | 40-150. | ||
| > 400--700. | 150-500. | 40-160. | 40-250. | |||
| > 700--900. | 300-700. | 50-180. | 40-300. | |||
| > 900-1300. | 400-900. | 70-250 | 40-400 | |||
